Equipment: hydrogen production PSA,water plant, power plant, steel plant smelting, chemical industry,water source spring engineering, environmental facility construction and other equipment
Applicable temperature: ≤550
Pressure level: Class150~Class2500
Valve specifications: NPS2~NPS160 Material: WCB,CF8,CF8M.etc
Note: Can be equipped with soft or hard fire-resistant covers, and the actuator can use high-temperature coating
| NO. | SECTION | Explanation | ||||||
| 1 | Valve size | American standard 2"-12" (inch) | National standard DN50-DN300 (mm) | |||||
| 2 | Valve feature code | Standard code | Fireproof type (fire resistant type) | |||||
| 3 | Connection type code | Wafer type | Lug type | Double Flange type | ||||
| 4 | Pressure class code | ANSI CLASS 150 lb | ANSI CLASS 300 lb | ANSI CLASS 600 lb | ||||
| 5 | Driving mode code | Manual | Bare stem | Worm gear transmission | Pneumatic | Electric | ||
| 6 | Body material code | Carbon steel | Stainless steel CF8 | Stainless steel CF8M | Stainless steel CF3 | Stainless steel CF3M | Monel | Hastelloy alloy |
| 7 | Stem material code | Martensite stainless steel 17-four PH | Stainless steel 304 | Stainless steel 316 | Stainless steel 1Cr13 | Stainless steel 2Cr13 | ||
| 8 | Butterfly plate material code | Stainless steel CF8 | Stainless steel CF8M | Stainless steel CF3 | Stainless steel CF3M | |||
| 9 | Seal of the seat material code | PTFE Teflon | RPTFE reinforced Teflon | PPL para polyphenylene | ||||
| VALVE SIZE AVAILABLE | ||
| Class 150 damp-on (Wafer ) | 1.5"~60" | DN40~DN1500 |
| Class 150 Lug type (LuG ) | 2"~60" | DN50~DN1500 |
| Class 150 flanged(Double Hange) | 3"~60" | DN80~DN1500 |
| Class 300 clamp-on (Wafer ) | 2"~24" | DN50~DN600 |
| Class 300 Lug type (LuG ) | 2. 5"~24" | DN65 ~DN600 |
| Cass 300 fbnged(Double Flange) | 3"~24" | DN80~DN600 |
Seal type
PT FE、R-PT FE、 Fireproof valve seat, etc.
Reliable fixing of shaft
The top of the shaft has an anti blowing structure toprevent the upper end of the shaft from moving out ofthe cover in case of accidental breakage
Convenient seat maintainance and servicing
Simply remove the insert to replace the valve seat, withoutthe need to disassemble the butterfly valve and shaft.
Provited with shut alt and control tunctons
-Has excellent control characteristics;
-Proportional variation of flow characteristic curve;
-Wide adjustment range;
-Even when used for control, it can still be tightly sealed.
Using a unique dynamic load sealing PTFE valve seat design, it hasgood elasticity and high reliability:
No need to add O-rings or metal components to maintain sealing;
The lip type sealing structure can compensate for changes intemperature and pressure,
Long service life and low maintenance workload;
Sealing test, achieving no bubble leakage in both directions
